Vietnam Thin-Walled Bearings 16 Series Manufacturer | Precision 16000 Series Ball Bearings Supplier

Bearing No.	Main Diameter			Recommended Installation Dimension
	d	D	B.C	r(Min)	da(Min)	da(Max)	Da(Max)
	Mm Inch	Mm Inch	Mm Inch	Mm Inch	Mm Inch	Mm Inch	Mm Inch
16001	12 0.4724	28 1.1024	7 0.2775	0.3 0.0118	14.0 0.551	… …	26.0 1.024
16002	15 0.5906	32 1.2598	8 0.3150	0.3 0.0118	17.0 0.669	… …	30.0 1.181
16003	17 0.6693	35 1.3780	8 0.3150	0.3 0.0118	19.0 0.748	… …	33.0 1.299
16004	20 0.7874	42 1.6535	8 0.3150	0.3 0.0118	22.0 0.866	… …	40.0 1.575
16005	25 0.9843	47 1.8504	8 0.3150	0.3 0.0118	27.0 1.063	… …	45.0 1.772
16006	30 1.1811	55 2.1650	9 0.3543	0.3 0.0118	32.0 1.260	… …	53.0 2.087
16007	35 1.3779	62 2.4409	9 0.3543	0.3 0.0118	37.0 1.457	… …	60.0 2.362
16008	40 1.5748	68 2.6772	9 0.3543	0.3 0.0118	42.0 1.654	… …	66.0 2.598
16006	45 1.7717	75 2.9528	10 0.3937	0.6 0.0236	48.2 1.898	… …	71.8 2.827
16010	50 1.9650	80 3.1496	10 0.3937	0.6 0.0236	53.2 2.094	… …	76.8 3.024
16011	55 2.1653	90 3.5433	11 0.4330	0.6 0.0236	58.2 2.291	… …	86.8 3.417
16012	60 2.3620	95 3.7400	11 0.4330	0.6 0.0236	63.2 2.488	… …	91.8 3.614
